Leroy Somer Automatic voltage regulator AVR R230

R230 Product Specification Download.pdf

We have Leroy Somer AVR R230 in our regulator stock!

Replacement Models: R220, R230, R250, R438, R448, R449, R450

Original Modules: D510C, R120, R129, R250, R438, R449, R450, R450M, R450T, R630, R726, R731

The Brands / Part No. here are for reference purpose only, our parts can exactly replace the original ones.

Part Numbers:

Leroy Somer AVR AEM110RE014 Automatic Voltage Regulator

SDMO AVR 330410345 Voltage Regulator

FG Wilson AVR 922-197 Voltage Regulator

Olympian AVR 922-197 Voltage Regulator

The alternator with Shunt excitation is self- excited with an Leroy Somer R230 voltage regulator.

The regulator monitors the exciter excitation current as a function of the alternator output voltage. Very simple in design, the alternator with shunt excitation has no sustaining short-circuit capacity.

Leroy Somer R230 AVR Characteristics

- Voltage regulation: around ± 0.5%.

- Voltage provide/sensing range 85 to 139 V (50/60 Hz)

- Rapid response time (500 ms) for a transient voltage variation amplitude of ± 20%

- Voltage setting

P1 - Stability setting

P2 - Power provide protected by 8 A fuse, slow blow action (tolerates 10 A for 10 s)

ST3- Frequency: 50 Hz with jumper - 60 Hz without ST3 jumper

P3 - Factory-set underspeed protection

2.2 - R230 Leroy Somer AVR option

Potentiometer for remote voltage adjustment, 1000 Ω / 0.5 W min: adjustment range ± 5%.

- Remove the ST4 jumper.
