Voltage Regulator GAVR AVR 20A AVR-20A GAVR-20A
AVR-20A
GAVR-20A
introduction
Warranty: 1 Year
Gross Weight: 0.4kg
Stock Status: In stock
Part No. : AVR-20A, GAVR-20A
Voltage Regulator GAVR AVR 20A AVR-20A GAVR-20A
We have AVR-20A AVR in our regular stock!
AVR GAVR-20A is Universal 20 Amp 1/2 Wave Self Excited Dip- Switch Programmable be Valtage alternator generator , which is suitable for brushless generator.
Technical data of AVR-20A
GAVR-20A is Universal 20 Amp 1/2 Wave Self Excited Dip-switch Programmable be Valtage alternator generator , which is suitable for brushless generator. |
*Sensing Input Voltage 220/400VAC,1phase 2wire |
*Power Input Voltage 180~240VAC, 1phase 2wire |
*Output Voltage Max.90VDC@240VAC input |
Current Continuous 6A |
Intermittent 15A for 10SEE |
Resistance Min.10Ω Max 100Ω |
*Voltage Build-up esidualvolts at AVR teminal >5VAC |
*External Volts Adjustment +/-7%with 1KΩ 1watt trimmer |
*Unit Power Dissipation Max.8Watt |
*Under Frequency Protection 60Hz system presets knee point at 57Hz |
*(Factory Settings) 50Hz system presets knee point at 47Hz |
