Voltage Regulator GAVR AVR 12A AVR-12A GAVR-12A

AVR-12A

GAVR-12A



introduction

Warranty: 1 Year

Gross Weight: 0.4kg

Stock Status: In stock

Part No. : AVR-12A, GAVR-12A

Voltage Regulator GAVR AVR 12A AVR-12A GAVR-12A


AVR-12A Product Specification Download.pdf



We have AVR-12A AVR in our regular stock!

Universal 7 Amp 1/2 Wave Self Excited Dip-Switch Programmalbe Automatic Voltage Regulator



Features of AVR AVR-12A

²  < 1% Regulation

²  220/440 VAC Programmable Input

²  Rugged Compact Design

²  With Under Frequency Protection

²  Soft Start Voltage Ramping

²  EMI Suppression

²  Built-in Hihg Capacity 10Amp Fuse



Specifications for AVR GAVR-12A

²  Sensing Input of AVR 12A : Voltage  180~260VAC,1phase2wire

²  Power Input for Voltage Regulator 12A: Voltage  180~260VAC,1phase2wire

²  Output of AVR GAVR-12A: Voltage  Max.90VDC@240VACinput

²  Current of Voltage Regulator AVR-12A:  Continuous 4A

²  Intermittent 7A for 10SEE.

²  Resistance  Min.12 Max.100

²  Voltage Build-up: Residual volts at AVR terminal>5VAC

²  External Volts Adjustment: 7%with 1K 1watt trimmer

²  Soft Start Ramp Time:  2sec.

²  Unit Power Dissipation:  Max.8Watt

²  EMI Suppression:  Internal Electromagnetic Interference Filtering

²  Thermal. Drift:  0.03%per change in AVR ambient

²  Under Frequency Protection:  60Hz system presets knee point at 55Hz

²  (Factory Settings) :  50Hz system presets knee point at 45Hz



Environment of GAVR 12A

Vibration 3G@100~2K Hz

Relative Humidity <95%

Operating Temperature -40~65

Storage Temperature -40~85
