GAC Magnetic Pickup Speed Sensor MSP6730 MSP6731
MSP6730
MSP6731
introduction
Warranty: 1 Year
Gross Weight: 0.15 kg
Stock Status: In stock
Replaced Brand: GAC
Part No. : MSP6730, MSP6731
Function: GAC MSP6730 Magnetic Pickup
Usage: GAC Speed Pickup MSP6730
Product Name: GAC Speed Pickup MSP6731
Compatible with: GAC Speed Sensor MSP6731
GAC Magnetic Pickup Speed Sensor MSP6730 MSP6731
We have Generator Speed Sensor MSP6730 MSP6731 in our regular stock!
The Brands here are for reference purpose only, our parts can exactly replace the original ones.
The Generator Speed Sensor MSP6730 detects when ring gear teeth, or other ferrous projections, pass the tip of the sensor. Electrical impulses are produced by the sensor’s internal coil and sent to the speed control unit. The signal from the Generator Speed Sensor MSP6731, teeth per second (Hz.), is directly proportional to engine speed. Speed sensors are available in various lengths in both U.S. and metric threads. Wire leads, military connectors, automotive connectors or stud terminals are also available. Over 30 styles currently available.
3/8-24 UNF Thread Generator Speed Sensor | ||||
Product # | Thread Length | Harness Length | Connector | With Mating Connector |
MSP6729 | 2.7in [69mm] | 6ft [1.8m] | Flying Leads | No |
MSP6730 Speed Sensor | 1.7 in. [43mm] | 6ft [1.8m] | Flying Leads | No |
MSP6731 Speed Sensor | 4.0in [102mm] | 6ft [1.8m] | Flying Leads | No |
MSP6737 | 2.7in [69mm] | 6in [1.8m] | Push-On Terminals | No |
MSP6740 | 1.7in [43mm] | 6ft [1.8m] | Packard | No |
MSP6742 | 2.7in [69mm] | 1ft [0.3m] | Flying Leads | No |
