Deep Sea Genset Auto Transfer Switch ATS DSE335

DSE335

DSE 335



introduction

Part No. : DSE335

Origin: Made in UK

Brand: DSE / DEEP SAE

Warranty: 1 Year

Gross Weight: 0.4 kgs

Usage: Deep Sea Genset ATS

Function: Genset Auto Transfer Switch

Product Name: Deep Sea Genset Auto Transfer Switch

Deep Sea Genset Auto Transfer Switch ATS DSE335



DSE335 Product Specification Download.pdf


The Deep Sea DSE335 Genset Auto Transfer Switch has been expertly developed to monitor the voltage and frequency of an incoming AC supply from two different sources. These sources can be generator or mains (utility), or a combination of both. The control module monitors Source 1 (S1) and Source 2(S2). When a failure occurs a start command is issued to the inactive source to take over the load. The module will return the load to the mains (utility) as soon as this becomes available.



OVERALL SIZE
240 mm x 181 mm x 42 mm (9.4” x 7.1” x 1.6”)

PANEL CUTOUT SIZE
220 mm x 160 mm (8.7” x 6.3”)

MAXIMUM PANEL THICKNESS
8.0mm (0.3”)

WEIGHT
0.9kg

PRODUCT VARIANTS
0335-01 - 335 Auto Transfer Switch Control Module - 12/24 Volt DC Supply
